Battery information
- Category: Reserve Power
- Type: Maintenance Free
- Range: : 1.3~3000ah
- Voltage: : 2V, 4V, 6V, 12V
Key Features
- Maintenance free operation
- Low self-discharge rate
- Safety valve installation for explosion proof
- Low self-discharge characteristic
- Long service life, the designed service life is 10 years
- Lead Aluminum calcium Tin alloy high energy, prevent corrosion
Description
- Maintenance free operation
- Low self-discharge rate
- Safety valve installation for explosion proof
- Low self-discharge characteristic
- Long service life, the designed service life is 10 years
- Lead Aluminum calcium Tin alloy high energy, prevent corrosion
Specifications
| Model | Voltage | Rate clCapacity | Dimension(mm) | Weight±2% | Terminal | |||
|---|---|---|---|---|---|---|---|---|
| ( V ) | (Ah) | L | W | H | (H over terminal) | (kg) | Type | |
| ZP-4M4.0AC | 4 | 4 | 47.5 | 47.5 | 102 | 107 | 0.45 | F01 |
| ZP-4M4.5AC | 4 | 4.5 | 47.5 | 47.5 | 102 | 107 | 0.49 | F01 |
| ZP-6M1.2AC | 6 | 1.2 | 97 | 24 | 51 | 56 | 0.26 | F00 |
| ZP-6M1.3AC | 6 | 1.3 | 97 | 24 | 51 | 56 | 0.28 | F00 |
| ZP-6M2.3AC（2.8AH case） | 6 | 2.3 | 66 | 34 | 98 | 103 | 0.50 | F04 |
| ZP-6M2.8AC | 6 | 2.8 | 66 | 34 | 98 | 103 | 0.54 | F04 |
| ZP-6M3.0AC | 6 | 3 | 125 | 33 | 60 | 65 | 0.57 | F00 |
| ZP-6M3.2AC | 6 | 3.3 | 125 | 33 | 60 | 65 | 0.62 | F00 |
| ZP-6M3.5AC（4AH case） | 6 | 4 | 70 | 47 | 100 | 105 | 0.66 | F01/F02 |
| ZP-6M3.5AC 4AH case） | 6 | 4.2-4.5 | 70 | 47 | 100 | 105 | 0.70 | F01/F02 |
| ZP-6M4.0AC | 6 | 4.5-5 | 70 | 47 | 100 | 105 | 0.72 | F01/F02 |
| ZP-6M4.5AC | 6 | 5 | 70 | 47 | 100 | 105 | 0.74 | F01/F02 |
| ZP-6M5AC（4AH case） | 6 | 5.2 | 70 | 47 | 100 | 105 | 0.77 | F01/F02 |
| ZP-6M5.5AC（4AH case | 6 | 5.2 | 70 | 47 | 100 | 105 | 0.80 | F01/F02 |
| ZP-6M5.5AC（4AH case） | 6 | 6.0 | 70 | 47 | 100 | 105 | 0.83 | F01/F02 |
| ZP-6M5AT（5AH case） | 6 | 5 | 170 | 35 | 70 | 76 | 0.83 | F03 |
| ZP-6M6.0AC（7AH case） | 6 | 6.5 | 151 | 36 | 93 | 98 | 1.00 | F01/F02 |
| ZP-6M7AC | 6 | 7 | 151 | 36 | 93 | 98 | 1.06 | F01/F02 |
| ZP-6M7.5AC | 6 | 7.5 | 151 | 36 | 93 | 98 | 1.10 | F01/F02 |
| ZP-6M8.0AC | 6 | 7.5 | 151 | 36 | 93 | 98 | 1.15 | F01/F02 |
| ZP-6M9.0AC | 6 | 9 | 151 | 36 | 93 | 98 | 1.31 | F01/F02 |
| ZP-6M10AC（10AH case） | 6 | 10 | 151 | 51 | 94 | 99 | 1.55 | F01/F02 |
| ZP-6M10AC （10AH case） | 6 | 11 | 151 | 51 | 94 | 99 | 1.60 | F01/F02 |
| ZP-6M12AC （10AH case） | 6 | 11.5 | 151 | 51 | 94 | 99 | 1.65 | F01/F02 |
| ZP-6M12AC（10AH case） | 6 | 12 | 151 | 51 | 94 | 99 | 1.73 | F01/F02 |
| ZP-6M14AC（10AH case） | 6 | 13 | 151 | 51 | 94 | 99 | 1.93 | F01/F02 |
| ZP-6M14AC (6V12AH special case） | 6 | 14 | 108 | 71 | 140 | 140 | 2.20 | F17 |
| 6V35AH(40AH case) | 6 | 35 | 162 | 89 | 163 | 171/175 | 5.38 | F08/F10 |
